Slow Glass Scripting Language Overview

Basic Concepts

It might be helpful to imagine a Slow Glass document as a playbook, containing scenes that can be performed, not by actors but by sprites, small graphical images. A scene contains one or more “cues” and when the conditions of the cue occur then one or more actions are carried out, usually involving sprites doing things.

There are also some overall “stage directions” that set things up, like the size of the stage, any background colours and various options, including the geographical location.

Unlike a traditional play, in which scenes are usually acted out in sequence, Slow Glass allows you perform scenes in any order, and perform multiple scenes at the same time. You can even have the same scene being performed at the same time in different parts of the stage or with different actors (sprites).

There is one scene, called “main” which can be thought of as the director, it controls all the other scenes, deciding when they are performed and making any changes necessary as the “play” proceeds.

Coordinate System

In order to instruct our sprite actors in their roles we need to tell them where to stand and where to move to. We do this in terms of coordinates called x and y which are whole numbers. 0,0 is the top left corner, x increases to the right and y increases down the page.

(Note, some animation or graphics systems have 0,0 in the bottom left with y growing upwards. If things don’t work as you expect in the vertical direction try changing the sign!)

Additionally sprites may overlap in the coordinate space so we need to know which one is in front. For this we use the idea of a sprite’s layer. This is an arbitrary value but sprites on higher layers are drawn in front of sprites on lower layers, so you can imagine layers as being like sheets of clear plastic sorted so that the lowest numbers are at the bottom.

You can also use (and may also see in the documentation) the term depth which has exactly the same meaning.

Naming Conventions

Where you are asked to supply a name it is best to assume that all names should be unique, i.e. they all share the same namespace. So do not have a scene, a sprite and a sound all using the same name. Although this might work I can’t guarantee it and you are only making things confusing for yourself anyway.

It is probably also best to avoid using the language keywords as names, so don’t call your scene “scene”! I also recommend NOT using all upper case names as these are used for built-in variables.

Specifying Duration

Where are duration is required an integer number will be looked for, followed by an optional time unit. Units can be “seconds”, “minutes”, or “hours” (or common abbreviations of those) and the default is seconds. Alternatively, you can use the phrase in the same time to repeat the most recent duration found.

Action Completion

We also need to understand the concept of action completion. Some actions complete as soon as they are executed, for example the place action. Others actions start a process that may end some time later, for example the actions that change sprite location or appearance over time. This is an important concept for the timing actions discussed elsewhere.

It should be noted that some actions start on-going activities that don’t have a defined “end”, these actions are deemed to have completed as soon as they start and don’t contribute towards the various timing and synchronisation actions. In the documentation for actions the completion event is shown for each action.

In the documentation of the action commands, it is always stated when, and under what circumstances the command “completes”. This is relevant to the trigger word then. This trigger will be succesful when all the immediately preceding commands have “completed”. Many commands complete as soon as they are encountered, but others complete when whatever action has been requested has completed, for example when moving a sprite to a specific location the command completes when the sprite reaches the location or the script sends a stop command to the sprite.

See also the wait command discussed in the system commands page.

Overall Structure

A Slow Glass file is just plain text - it is fairly flexible in the organisation and structure of the files containing the script, but I suggest the following guidelines for ease of use.

Description

I suggest that you start each file with a notes / endnotes pair of directives, with a free-format explanation of the file between them.

Options and Stage Directions

Following that I would group together all the options that affect the whole file, so things like stage height and stage width, along with any option directives.

Main Scene

The main scene then follows, that is a sequence of cues and actions that constitute the “top level” of the script. These will be automatically enabled when the script starts to run and the cues will start being checked for activation. For simple scripts this may all that is needed, in which case you don’t need to name the scene, just provide the cues and actions.

Additional Scenes

However, for more complex scripts you will likely benefit from breaking things down into individual scenes, you can define as many addtional scenes as you need, starting each scene with scene {name} and ending it with end scene. Scene names should be unique and must contain at least one letter (re-used names will overwrite existing scenes).

End File

The file can be finished with end file, which will cause all subsequent content to be ignored, or you just end the file as normal.

Scene Structure

Each scene, including the top level main scene is structured in the same way - as a set of grouped lines. Each group consists of one or more cues, followed by one or actions, each on a separate line. It can be helpful to indent lines to show the hierarchy, for example here are two groups, indicated by horizontal lines:

scene {name}
---------------
    cue-1
        action-1 for cue-1
        action-2 for cue-1
---------------
    cue-2
    cue-3
        action-3 for cue-2/3
        action-4 for cue-2/3
---------------
end scene

To make things even more obvious you can use marker directives like this:

scene {name}
    cues
        cue-1
    actions
        action-1
        action-2
    cues
        cue-2
        cue-3
    action
        action-3
end scene

All of the actions in a group will be executed if a cue is activated.

Note that in most cases the ordering of these groups doesn’t matter. At regular intervals the program will check all of the cues and it any of cue conditions are met it will execute the attached actions. You should however be aware that this checking of cues happens in the order that they appear in the file, so take care if you are relying on side effects (like setting the value of variable) to “communicate” between groups of actions.

Multiple Cues

If there is more than one cue in a group you can control whether the actions are executed if any cue condition is met, or if they will be executed only if all the cues conditions are met. This requires the presence of the marker directive for cues:

scene {name}
---------------
    cue on all
        cue-1
        cue-2
    action-1
    action-2
---------------
    cue on any
        cue-3
        cue-4
    action-3
    action-4
---------------
end scene

The default behaviour is to execute the actions when any cue is activated.

Care should be taken with the all case to make sure that the cues are not mutually exclusive and will never happen together!
